Compliance Standards:
- ASTM C430, BS EN 451-2
Applications:
- Wet Sieving Apparatus is used for determining the fineness of fly ash.
Details:
The apparatus comprises of following parts and accessories
- A special stainless steel sieve, 0.045 mm opening, No.325 stainless steel wire cloth. The frame is 2 inches (50.8 mm) diameter, and 3 inches (76.2 mm) deep from rim to cloth.
- A spray nozzle Ø 17.5 mm diameter with 17 holes, Ø 0.5 mm oriented and spaced to conform to the standards.
- Supplied complete with a pressure gauge of Ø 80 mm diameter and fittings for connection to the water supply.
