High Strain Pile Driving Analyzer

Application:

1. Standard Test Method for High Strain Dynamic Testing of Deep Foundations ASTM D4945-17
2. Standard Test Method for Low Strain Impact Integrity Testing of Deep Foundations ASTM D5882-16

Features:

1. Pile Driving Monitoring : With fast signal acquisition pace, the 60 hammers/min signal acquisition can be completed and the pile driving monitoring testing can be carried out in real time.
2. Strain transducer installation monitoring, automatic balance adjustment of strain bridge : Real-time monitoring of strain sensor deformation status; Reduce the impacts of initial deformation of strain transducer on signal acquisition and eliminate the signal zero drift.
3. Intuitive Result : Analysis results by Case method, F-ZV curves and upper and lower traveling wave curves are displayed in the field.
4. Instantaneous floating point amplification technology : Compatible with the distortion less acquisition of strong and weak signals. The three-dimensional correction function for shallow defect is owned and the defect can be located accurately.
5. Large Capacity Ultra-thin Battery : 9mm ultra-thin large-capacity battery, battery life ≥10h and removable. Can be equipped with a backup battery.
6. Industrial-grade : Newly upgraded industrial-grade capacitive touch screen, smooth and precise operation, adapt to strong light environment.

Standard supply:

1. High strain pile bearing tester - RSM-PDT (D)
2. High strain test cable : 20 meter
3. Strain transducer - 3 pcs - 3M
4. Piezoelectric accelerometer - 2 Pcs-5M
5. Cable bag
6. Power Adaptor - 8.4V - 5A - 2 Pcs
7. Tool kit: U disk, tape measure, wrench
8. Expansion Bolt
9. Instrument Container

Optional for PDA:

• Superdog and RSM-CAPWAP software

Optional for PIT:

1. Accelerometer with Cable 5 m
2. Hammer

Note:

EIE Instruments Pvt Ltd in Partnership with Wuhan Sinorock Technology Co. Ltd

1. EIE Instruments Pvt Ltd, a leader in civil engineering testing instruments, has partnered with Wuhan Sinorock Technology Co. Ltd, a global expert in foundation pile testing.
2. This collaboration brings advanced solutions for Pile Integrity Testing, Dynamic Analysis, Cross-Hole Sonic Logging, Static Load Testing, and Drilling Monitoring, combining EIE’s trusted manufacturing and service with Sinorock’s innovative technology.
